Product Description

Weight 4.2 kg
Maximum Battery Current 60 Amps
Nominal Maximum Solar Input 12V – 800W, 24V – 1600W, 48V – 3200W
Peak Efficiency 99%
Nominal System Voltage 12, 24, 36 or 48 volts DC
Max Solar Open Circuit Voltage 150 volts DC
Battery Operating Voltage Range 8-72 volts DC
Maximum Self Consumption 2.7 Watts
Transient Surge Protection 4500 Watts/port
Electronic Protections Solar: Overload, Short Circuit, High Voltage. Battery: High Voltage
Communication Ports MeterBus, RS-232, EIA-485, Ethernet
Dimensions 29.1 x 13.0 x 14.2 cm
